ASUS GeForce RTX 4060 LP BRK OC Edition 8GB GDDR6

AI Performance: 245 AI TOPS
NVIDIA Ada Lovelace Streaming Multiprocessors: Up to 2X performance and power efficiency
4th Generation Tensor Cores: Up to 4x performance with DLSS 3 vs. brute-force rendering
3rd Generation RT Cores: Up to 2x ray tracing performance
OC edition: Boost Clock 2520 MHz (OC Mode)/ 2490 MHz (Default Mode)
IP5X dust resistance offers protection from particle ingress for better durability.
Dual ball fan bearings can last up to twice as long as sleeve bearing designs.
A 2-slot design maximizes compatibility and cooling efficiency for superior performance in small chassis.
Auto-Extreme technology uses automation to enhance reliability.
GPU Tweak III provides intuitive performance tweaking, thermal controls, and system monitoring.

Specifications

Model

RTX4060-O8G-LP-BRK
Graphic Engine

NVIDIA® GeForce RTX™ 4060
Bus Standard

PCI Express 4.0
OpenGL

OpenGL®4.6
Video Memory

8GB GDDR6
Engine Clock

OC mode : 2520 MHz
Default mode : 2490 MHz (Boost)
CUDA Cores

3072
Memory Speed

17 Gbps
Memory Interface

128-bit
Resolution

Digital Max Resolution 7680 x 4320
Interface

Yes x 2 (Native HDMI 2.1a)
Yes x 2 (Native DisplayPort 1.4a)
HDCP Support Yes (2.3)
Maximum Display Support

4
NVlink/ Crossfire Support

No
Accessories

1 x Speedsetup Manual
1 x LP bracket
Software

ASUS GPU Tweak III & GeForce Game Ready Driver & Studio Driver: please download all software from the support site.
Dimensions

188 x 69 x 39 mm
7.4 x 2.72 x 1.53 inches
Recommended PSU

550W
Power Connectors

1 x 6-pin
Slot

2 Slot
Note

* Our wattage recommendation is based on a fully overclocked GPU and CPU system configuration. For a more tailored suggestion, please use the “Choose By Wattage” feature on our PSU product page: https://rog.asus.com/event/PSU/ASUS-Power-Supply-Units/index.html
AI Performance

245
